Ubiquiti USW-Pro-Max-16-PoE Pro Max 16 PoE 16-Port POE++ Layer 3 Etherlighting Switch

Ultimate Layer 3 Etherlighting™ Switch Discover the Ubiquiti USW-Pro-Max-16-PoE, a powerful 16-port Layer 3 switch featuring Etherlighting™ technology, 2.5 GbE PoE++ output, and versatile mounting...

$618.45 SGD $567.39 SGD SAVE $51.06 SGD

american expressapple paygoogle paymasterpaypalshopify payvisa
Vendor: Ubiquiti
SKU: USW-Pro-Max-16-PoE
Barcode:
Availability : In Stock Pre order Out of stock

Frequently Bought Together

Total price:$773.45 $716.68
Description

Ultimate Layer 3 Etherlighting™ Switch

Discover the Ubiquiti USW-Pro-Max-16-PoE, a powerful 16-port Layer 3 switch featuring Etherlighting™ technology, 2.5 GbE PoE++ output, and versatile mounting options for seamless network management.

Highlights

  • 16-port Layer 3 Etherlighting™ switch
  • 2.5 GbE, PoE++ output
  • Versatile desktop, wall, and rack mounting

Key Features

  1. Etherlighting™ Technology
    • Illuminates ports to indicate location, speed/link, and native VLAN/network.
    • Optimized brightness with UniFi Etherlighting Patch Cables.
  2. Advanced Connectivity
    • (4) 2.5 GbE PoE++ ports and (12) GbE PoE+ ports.
    • (2) 10G SFP+ ports for high-speed uplinks.
  3. High Power Availability
    • 180W total PoE availability.
    • PoE++ output with up to 60W per port.
  4. Silent, Fanless Design
    • Ensures quiet operation with fanless cooling.
  5. Versatile Mounting Options
    • Suitable for desktop, wall, and rack installations (rack mount accessory required).

Mechanical Specifications

  • Dimensions: 325.1 x 160 x 43.7 mm (12.8 x 6.3 x 1.7")
  • Weight: 2.1 kg (4.6 lb)
  • Enclosure Material: SGCC steel

Hardware Specifications

  • Management Interface: Ethernet In-Band
  • Networking Interface: (12) GbE RJ45 ports, (4) 1/2.5 GbE RJ45 ports, (2) 10G SFP+ ports
  • PoE Interface: (12) PoE/PoE+ (Pins 1, 2+; 3, 6-), (4) 60W PoE++ (Pair A 1, 2+; 3, 6-) (Pair B 4, 5+; 7, 8-)
  • Total Non-Blocking Throughput: 42 Gbps
  • Switching Capacity: 84 Gbps
  • Forwarding Rate: 62.496 Mpps
  • Power Method: DC adapter
  • Power Supply: 54V, 210W
  • Max. Power Consumption: 30W (Excluding PoE output)
  • Total Available PoE: 180W
  • Max. PoE Wattage Per Port by PSE: PoE: 15.4W, PoE+: 30W, PoE++: 60W
  • Voltage Range PoE Mode: PoE: 44—57V, PoE+/PoE++: 50—57V
  • LCM Display: (1) 1.3" touchscreen
  • Button: Factory reset
  • Ambient Operating Temperature: -5 to 40° C (23 to 104° F)
  • Ambient Operating Humidity: 10 to 90% noncondensing
  • Certifications: CE, FCC, IC

Switching Features

  • Layer 2 Features: IGMP snooping, STP/RSTP, Port isolation, Storm control, Voice VLAN, Port mirroring, LACP, Rate limiting, MAC address blocking, Flow control, 802.1X control, Jumbo frames, Loop protection, DHCP snooping/guarding, Egress rate limit, LLDP-MED, Port restricted by MAC, Device isolation with ACLs.
  • Layer 3 Features: DHCP, DHCP relay, Inter-VLAN routing, Static routing, Network isolation with ACLs.

Summary

The Ubiquiti USW-Pro-Max-16-PoE is a robust and versatile networking solution, offering advanced Layer 3 features, high PoE power availability, and Etherlighting™ technology for easy port management. Its silent, fanless design and versatile mounting options make it an excellent choice for any professional network environment.

Specs

Specification Details
Mechanical
Dimensions 442.4 x 399.6 x 43.7 mm (17.4 x 15.7 x 1.7")
Weight Without Mounting Brackets 6.2 kg (13.7 lb)
Weight With Mounting Brackets 6.3 kg (13.9 lb)
Enclosure Material SGCC steel
Hardware
Management Interface Ethernet In-Band
Networking Interface (32) GbE RJ45 ports, (16) 1/2.5 GbE RJ45 ports, (4) 10G SFP+ ports
PoE Interface (32) PoE/PoE+, (16) 60W PoE++
Total Non-blocking Throughput 112 Gbps
Switching Capacity 224 Gbps
Power Method Universal input 100—240V AC, 50/60 Hz, USP RPS DC input
Power Supply AC/DC, internal, 820W
Supported Voltage Range 100—240V AC
Max. Power Consumption 100W (Excluding PoE output)
Total Available PoE 720W
Max. PoE Wattage per Port by PSE PoE: 15.4W, PoE+: 30W, PoE++: 60W
Voltage Range PoE Mode PoE: 44—57V, PoE+: 50—57V
LCM Display (1) 1.3" touchscreen
Button Factory reset
Operating Conditions
Operating Temperature -5 to 40° C (23 to 104° F)
Operating Humidity 10 to 90% noncondensing
Certifications CE, FCC, IC
Etherlighting™ & LEDs
Ethernet Locating, Speed/link, Native VLAN/network
SFP+ Locating, Speed/link, Native VLAN/network
System LED Status
RPS LED Status
