Ubiquiti UACC-ETH-SP-DIN 10GbE POE++ 20kA Single Port Ethernet Surge Protection

Industrial-Grade Surge Protection for 10GbE and PoE++ Networks

Safeguard your network infrastructure with the Ubiquiti UACC-ETH-SP-DIN, a high-performance single-port Ethernet surge protector designed for 10GbE and PoE++ systems. Engineered with a robust 20kA discharge capacity and bidirectional protection, it shields connected devices from electrical surges, lightning strikes, and transient voltage spikes. Ideal for industrial and enterprise environments, it supports wall and DIN rail mounting for flexible installation.

Highlights

• 20kA Surge Protection: High-capacity discharge protection for critical network hardware.

• 10GbE and PoE++ Compatibility: Ensures reliable performance with modern high-speed networks.

• Bidirectional Circuit Protection: Protects both incoming and outgoing network lines.

• DIN Rail and Wall Mounting: Supports versatile installation options.

• Multiple Grounding Points: Improves electrical safety and performance stability.

• Wide Operating Range: Performs in extreme environments from -40°C to +80°C.

Key Features

High-Performance Electrical Protection

• Discharge Current Capacity: Rated for up to 20kA, ensuring effective surge suppression.

• DC Spark-Over Voltage: 90V @ 100V/s for precise response to voltage fluctuations.

• Impulse Spark-Over Voltage: 600V @ 1kV/µs for transient surge response.

• Data Line Protection: Maintains up to 10 Gbps Ethernet transmission without interference.

• PoE++ Support: Fully supports Power over Ethernet standards for seamless integration.

Rugged and Reliable Design

• Industrial-Grade Build: Constructed with polycarbonate and SGCC steel for durability.

• Compact Size: 89 x 25.5 x 37.4 mm for efficient use in control panels and racks.

• Lightweight Construction: Weighs only 74 g for easy installation.

• DIN Rail and Wall Mount Options: Simplifies deployment in both commercial and industrial setups.

Enhanced System Protection

• ESD and EMP Protection: Absorbs transient current with rapid response to voltage surges from 100V/s to 1kV/µs.

• High Insulation Resistance: Up to 1G ohm @ 50V ensures signal integrity and electrical isolation.

• Low Capacitance: 1.0 pF @ 1 MHz for minimal signal degradation.

• Multiple Grounding Points: Allows secure and redundant grounding for maximum reliability.

Summary / Conclusion

The Ubiquiti UACC-ETH-SP-DIN delivers robust surge protection for high-speed 10GbE and PoE++ network equipment. Its durable construction, bidirectional protection, and flexible mounting options make it ideal for safeguarding mission-critical systems in commercial, industrial, and data center environments. With superior response speed and 20kA discharge capability, it ensures network stability and longevity.

Ubiquiti UACC-ETH-SP-DIN 10GbE PoE++ 20kA Single Port Ethernet Surge Protector

The Ubiquiti UACC-ETH-SP-DIN is a professional-grade Ethernet surge protector providing bidirectional protection for high-speed 10GbE and PoE++ connections. Designed for reliable indoor installation, it safeguards critical networking equipment from electrical surges up to 20kA while maintaining full data throughput. The unit features wall and DIN rail mounting options with multiple grounding points for flexible, secure installations.
