TP-Link VIGI NVR1108H-W 8 Channel Wi-Fi Network Video Recorder
Effortless Multi-Channel Video Recording with Wireless Flexibility The TP-Link VIGI NVR1108H-W 8-Channel Wi-Fi Network Video Recorder offers seamless video management and high-quality recording with easy...
Frequently Bought Together
Description
Effortless Multi-Channel Video Recording with Wireless Flexibility
The TP-Link VIGI NVR1108H-W 8-Channel Wi-Fi Network Video Recorder offers seamless video management and high-quality recording with easy setup. Featuring support for 4K HDMI output, H.265+ compression, and remote monitoring, this NVR is an ideal choice for small to medium-scale security systems, allowing for both wired and wireless camera pairing.
Highlights
- 8-Channel Live View: Monitor up to 8 channels in real time with synchronized playback†
- 4K HDMI Video Output: Crystal-clear video output with simultaneous HDMI and VGA support
- Wireless Pairing Support: Built-in router module for seamless wireless camera pairing*
- H.265+ Compression: Efficient storage that reduces bandwidth and space requirements
- 1 SATA Interface: Supports HDD up to 10TB** for extended recording duration
- Remote Monitoring: Access live view and playback remotely for real-time surveillance
Key Features
Multi-Channel High-Definition Video
- 8-Channel Decoding: Supports 8-ch @ 2MP (25fps) or 4-ch @ 4MP (25fps) for flexible camera setups.
- 4K HDMI and VGA Output: Dual output options for high-resolution monitoring and playback.
Flexible and Simple Setup
- Wireless Pairing: Connect compatible wireless cameras directly through the built-in router module.*
- Quick HDD Installation: Tool-free setup; simply insert and secure the HDD for instant storage.
Smart Storage & Compression
- H.265+ Compression Technology: Reduces bandwidth and storage needs without compromising quality.
- SATA Interface: Accommodates up to 10TB for long-term video retention.
User-Friendly Configuration
- Auto Initialize: Quick configuration with one-click setup for cameras and HDD parameters.
- Remote Monitoring: Check live feed and playback from anywhere, anytime, via app or web.
Summary
The TP-Link VIGI NVR1108H-W 8-Channel Wi-Fi Network Video Recorder delivers powerful recording and monitoring with wireless flexibility and efficient storage. With high-definition output, remote access, and simple setup, this NVR is designed to streamline security management for businesses or homes needing reliable video surveillance.
Specs
TP-Link VIGI NVR1108H-W 8 Channel Wi-Fi Network Video Recorder
| Specification | Details |
|---|---|
| IP Video Input | 8-Channel |
| Incoming Bandwidth | 80 Mbps |
| Outgoing Bandwidth | 60 Mbps |
| HDMI Output Resolution | 1 Channel, Resolution: 3840×2160/30Hz, 1920×1080/60Hz, 1680×1050/60Hz, 1440×900/60Hz, 1280×1024/60Hz, 1280×720/60Hz |
| VGA Output Resolution | 1 Channel, Resolution: 1920×1080/60Hz, 1680×1050/60Hz, 1440×900/60Hz, 1280×1024/60Hz, 1280×720/60Hz |
| Video Output Mode | HDMI/VGA Simultaneous Output |
| Multi-View Display | 1/4/6/8 |
| Audio Compression | G.711A/G.711U/G.726 |
| Video Compression | H.265+/H.265/H.264+/H.264 |
| Record Resolution | 8 MP / 5 MP / 4 MP / 3 MP / 1080p / UXGA / 720p / VGA / 4CIF / DCIF / 2CIF / CIF / QCIF |
| Synchronous Playback | 8-Channel |
| Record Mode | • Manual Recording • Scheduling Recording • Motion Detection Recording |
| Playback Mode | • Instant, Regular, Tag, Event Playback |
| Backup Mode | • Regular Backup • Video Clip Backup |
| Network Protocol | UPnP, NTP, SMTP, TCP/IP, UDP, ICMP, HTTP, HTTPS, DHCP, RTSP, SSL/TLS, RTP, IPv4, ARP |
| Mobile Phone Access | Android, iOS |
| Web Browser | Chrome (57+), Firefox (52+), Edge (91+) |
| Interoperability | ONVIF Profile S, CGI |
| Wireless Standards | IEEE 802.11b/g/n |
| Wi-Fi Channels | • UN: 1-13 • US: 1-11 |
| Frequency | 2.4 GHz |
| Radio Bandwidth | Auto, 20M, 40M |
| Wireless Rate | 300Mbps (802.11n), 2 × 2 MIMO |
| Wireless Security | WPA-PSK/WPA2-PSK |
| Network Interface | • 1× RJ-45 10/100 Mbps Self-Adaptive WAN/LAN Ethernet Interface • 1× RJ-45 10/100 Mbps Self-Adaptive LAN Ethernet Interface |
| USB Interface | 2× USB 2.0 |
| Audio Interface | 1-ch RCA Input, 1-ch RCA Output |
| Speaker | 1; Real-time Audio Output without Peripherals |
| SATA Interface | 1 SATA Interface |
| HDD Capacity | Up to 10 TB per HDD |
| General Alarm | • Motion Detection • Video Tampering • Scene Change Detection • Intrusion Detection • Region Exiting/Entering Detection • Loitering Detection • Object Abandoned/Removal Detection |
| Anomaly Alarm | • Video Loss • Offline and IP Conflict • Disk Exception • Login Exception |
| Alarm Linkage | • Recording • White Light Alarm • Log • Audible Alarm |
| Operating Temperature | • NVR: -10–55 °C • Power Adapter: 0–40 °C |
| Storage Temperature | -40–70 °C |
| Operating Humidity | 10%–90% RH Non-Condensing |
| Package Contents | • VIGI Network Video Recorder • Power Adapter • HDD Screws • Mouse • Quick Installation Guide |
| Dimensions (W x D x H) | Excluding Antennas: 200.3 × 200.3 × 43 mm (7.9 × 7.9 × 1.7 in) |
| Power Supply | DC 12V/2A |
| Net Weight | 0.5 kg |
| Gross Weight | 1.0 kg |
| Power Consumption | • 5.7 W (Without Disk) • 16.3 W (With Disk) |
| Antenna | • Quantity: 2 • Type: 2.4GHz Non-detachable • Gain: 5.3dBi • Length: 198.8 mm (long side), 189 mm (short side) |
| Certifications | BSMI, CE, HDMI, JRF, KC, NCC, NTRA, VCCI |
