D-Link DGS-1100-08PV2 8-Port Gigabit PoE Smart Managed Switch
The Optimal Gigabit PoE Smart Managed Switch for Modern Deployments Enhanced Management and Power in One Compact Package Embracing the D-Link DGS-1100 series' signature style,...
The Optimal Gigabit PoE Smart Managed Switch for Modern Deployments
Enhanced Management and Power in One Compact Package
Embracing the D-Link DGS-1100 series' signature style, the DGS-1100-08PV2 presents administrators with the perfect balance between simplified management and potent capability. Equipped with a comprehensive web user interface, the navigation and control over pivotal Layer 2 functionalities—from VLANs to STP and link aggregation—are effortless. Couple this with an arsenal of security features like IGMP snooping, Static MAC, and Storm Control, and you have a switch geared for versatile deployments.
Key Features
-
PoE Capabilities: With 8 x 10/100/1000BASE-T PoE ports, this switch can power devices such as CCTV, IP Cameras, VoIP phones, Wi-Fi access points, and industrial IoT. This IEEE 802.3at PoE support ensures flexibility in device installation, especially in locations lacking immediate power sources.
-
Elevated PoE Power Budget: With a robust 64W PoE power budget, multiple devices can be effectively powered, ensuring uninterrupted operations.
-
Compact Yet Powerful: While its compact design ensures convenience in placement, it does not compromise on capability, making it a favorite for diverse settings.
-
Silence is Golden: Thanks to its fanless design, the switch operates without making a sound, perfect for quiet environments where noise can be a distraction.
-
Eco-Conscious Operations: The innovative D-Link Green energy-saving features have been integrated, highlighting our commitment to efficiency and environmental sustainability.
-
Advanced Management Tools: Through its complete web interface, administrators are equipped with an extensive suite of management tools, simplifying tasks and ensuring optimal switch performance.
| Feature | Specification |
|---|---|
| Auto MDI/MDIX | ✔️ |
| 10/100/1000BASE-T PoE ports (802.3af/at) | 8 |
| 802.3bt 90W Support | ❌ |
| 10/100/1000BASE-T ports (Including PoE ports) | 8 |
| Gigabit SFP ports | 0 |
| Port-based Bandwidth Control | ✔️ |
| Class of Service (CoS) | ✔️ |
| 802.3x Flow Control | ✔️ |
| Store-and-Forwarding | ✔️ |
| Comply with RoHS | ✔️ |
| Energy Efficiency Ethernet (EEE) | ✔️ |
| FAN | Fanless |
| Jumbo Frame | 9,216 bytes |
| Loopback Detection (LBD) | ✔️ |
| IGMP Snooping | ✔️ |
| 802.1AX Link Aggregation | ❌ |
| 802.3ad Link Aggregation | ❌ |
| SNMP | ✔️ |
| Web-based GUI | ✔️ |
| D-Link Discover Protocol (DDP) | ✔️ |
| D-Link Network Assistant | ✔️ |
| Port Mirroring | ✔️ |
| Cable Diagnostics | ✔️ |
| Switch Capacity | 16 Gbps |
| Max. Packet Forwarding Rate | 11.9 Mpps |
| Maximum Power Consumption (PoE On) | 78W |
| Maximum PoE Budget | 64W (30W max per PoE port) |
| Rate Limiting | ✔️ |
| Power Input | External Power Adapter |
| Queue Handling | ✔️ |
| Strict Priority Queue (SPQ) | ✔️ |
| Weighted Round Robin (WRR) | ✔️ |
| SSL | ✔️ |
| Broadcast/Multicast/Unicast Storm Control | ✔️ |
| Traffic Segmentation | ✔️ |
| D-Link Safeguard Engine | ❌ |
| DoS Attack Prevention | ❌ |
| 802.1D Spanning Tree (STP) | ✔️ |
| 802.1w Rapid Spanning Tree (RSTP) | ✔️ |
| Dimension | 171 x 97.8 x 28.6 mm |
| Weight | 0.6kg |
| Operation Temperature | 0-40°C |
| 802.1Q VLAN | ✔️ |
| Port-based VLAN | ✔️ |
| Voice VLAN | ✔️ |
| Auto Surveillance VLAN | ✔️ |
| Asymmetric VLAN | ✔️ |
| EMI Certification | FCC Class B, CE Class B, VCCI Class B, BSMI |
| Safety Certification | cUL, CE LVD, CB, BSMI |
