4-Bay NAS

QNAP TS-462 vs Synology DS423+: 2.5GbE, Memory and Media Workloads

A practical four-bay comparison: QNAP’s 2.5GbE and PCIe options, Synology’s DSM workflow, and the memory and media details to check before buying.

About 6 min read
QNAP TS-462 vs Synology DS423+: 2.5GbE, Memory and Media Workloads - ACE Peripherals

TS-462 offers a built-in 2.5GbE connection, PCIe expansion and HDMI; DS423+ offers a four-bay DSM platform with two Gigabit ports. Both use Intel Celeron processors with integrated graphics. Choose for the application, network and supported expansion, then check the exact memory revision and recovery plan.

A four-bay NAS can hold family photos, serve a small creative team or receive computer backups. Those uses do not stress the same parts of the system. Before choosing between these models, decide whether the main requirement is file access, media playback, applications or a manageable backup routine.

The Hardware That Changes the Decision

Genuine QNAP TS-462 white and gold four-bay NAS
QNAP TS-462

Check the exact memory revision, suitable PCIe options and complete 2.5GbE connection.

Genuine Synology DS423+ black four-bay NAS
Synology DS423+

Check DSM application support, supported M.2 roles and the configuration of its two Gigabit ports.

Planning point QNAP TS-462 Synology DS423+
Processor Intel Celeron N4505, two cores, 2.0 GHz with burst up to 2.9 GHz Intel Celeron J4125, four cores, 2.0 GHz with burst up to 2.7 GHz
Graphics Integrated Intel UHD Graphics Integrated Intel graphics; absence of HDMI does not mean absence of a GPU
Main drive bays Four SATA bays Four SATA bays
Network One 2.5GbE port Two Gigabit ports
M.2 Two M.2 2280 PCIe Gen 3 ×1 slots; verify supported SSD role Two M.2 2280 NVMe slots; supported caching or storage-pool configurations
Expansion / display PCIe Gen 3 ×2 expansion slot; HDMI 2.0 output No PCIe expansion slot or HDMI output
Memory Current TS-462-4G specification lists two SO-DIMM slots, up to 16 GB; verify unit revision 2 GB onboard plus one supported 4 GB module, up to 6 GB

The TS-462 memory detail deserves attention: older and regional material can describe a different configuration. Do not order RAM from the family name alone. Confirm the exact SKU and hardware revision, installed arrangement and supported module list. Both systems also need compatible drives rather than a generic capacity promise.

Will 2.5GbE Make Your File Copies Faster?

HOW THE CONNECTION WORKS

One Fast Connection or Several Shared Connections?

Two Gigabit sockets do not automatically double one file copy.

01 One client and one ordinary flow

Computer network portSwitch + one negotiated linkNAS port + disk poolThe slowest stage still matters

A 2.5GbE NAS linked to a Gigabit switch still has a Gigabit network stage.

02 Several users or supported SMB

Multiple client requestsConfigured links / SMB pathsSupported NAS + client softwareCheck the actual configuration

Link aggregation and SMB Multichannel are different features with different requirements.

This schematic explains the paths. It does not claim measured speed, automatic link aggregation or universal SMB Multichannel support.

TS-462 has a straightforward advantage when a computer, switch and cable path can all use 2.5GbE. It can remove a Gigabit network stage. That still does not establish the speed of a folder containing thousands of tiny files, an encrypted workload or a busy disk pool.

DS423+ has two physical Gigabit ports. Link aggregation can help an appropriate shared deployment, but it does not automatically double one conventional file-copy stream. SMB Multichannel is a separate software feature that needs support and correct configuration at both ends. Check the actual DSM, client and network arrangement before using either in a performance calculation.

If copies are already slow, use the NAS transfer troubleshooting guide to locate the busy stage. Changing the NAS model without checking the client connection, pool activity and file workload can leave the main problem untouched.

Media Playback Is More Than HDMI or a GPU Tick

TS-462’s HDMI connection can be useful for supported local-display applications. DS423+ has no HDMI port, but its processor does include graphics capability. The next question is whether the chosen server application can use that hardware for the exact codec, resolution, subtitles and audio format.

Direct play is different from transcoding. When a television or player can decode the original file, the NAS mainly reads and serves it. When conversion is required, the server needs additional resources and compatible software. An application licence may also be required for hardware acceleration. Neither a processor name nor an HDMI socket guarantees every streaming service, DRM system or video conversion.

Give the SSDs and Four Drive Bays a Clear Job

An M.2 socket does not mean any NVMe drive can be used for every purpose. Check the supported SSDs, operating-system version and intended cache or storage-pool role. A cache can help certain repeated or random workloads; it does not create a faster Ethernet port or guarantee better sequential transfers.

Calculate usable capacity after the chosen protection layout, formatting and retained versions. Four 8 TB drives provide 32 TB raw. An equal-drive RAID 5 example leaves roughly 24 TB before other deductions, while RAID 6 leaves roughly 16 TB. Those figures are layout arithmetic, not a backup and not a promise that the whole amount is available for new files.

Use the RAID capacity calculator for the proposed drives. Keep expansion compatibility and recovery separate from raw-capacity headlines; there is no useful universal “maximum scalable TB” figure without specifying enclosures, drives and software support.

Choose for the Working Day and the Recovery Day

A small studio with a compatible 2.5GbE computer and large sequential transfers has a reason to examine TS-462’s network and expansion options. A home office that values a particular DSM photo, sharing or backup routine has a reason to examine DS423+. Neither example makes one brand universally simpler or faster.

List the applications first, then price the complete supported configuration: drives, memory if needed, network changes and an independent backup destination. Test a representative file restore. Choose TS-462 when its extra connections solve a real requirement; choose DS423+ when its supported workflow fits the users and available network. Four bays should serve that plan, rather than define it.

Frequently Asked Questions

Does DS423+ lack integrated graphics?

No. Its Intel Celeron J4125 includes integrated graphics. Application access to hardware acceleration, supported media formats and licences are separate checks.

Can TS-462 memory be upgraded?

Current TS-462-4G hardware specifications list two SO-DIMM slots and up to 16 GB. Verify the exact unit revision because older or regional documentation can describe a different arrangement.

Do the DS423+ ports make one copy run at 2Gb/s?

Not automatically. Ordinary link aggregation does not double every single flow. Supported SMB Multichannel has its own client, NAS and configuration requirements.

Can any NVMe SSD become a storage pool?

No. Check the NAS model, operating-system version, supported SSD list and approved cache or storage-pool role.

Does HDMI guarantee every 4K video will play?

No. Playback depends on the application, codec, audio, subtitles, display path and any relevant licence or DRM requirements.

Is RAID enough to protect the files?

No. Keep a versioned independent backup and test recovery. Redundant drives do not cover every deletion, compromise or site-level failure.
