Ubiquiti ES-16-XG EdgeSwitch 16-Port XG 10G SFP+ RJ45 Aggregation Switch

High-Bandwidth 10G Aggregation with 16 Fully Managed Ports The Ubiquiti ES-16-XG EdgeSwitch delivers powerful Layer 2 management and 160 Gbps of total non-blocking throughput. With 12 SFP+ fiber ports and 4 10G RJ45 ports, it's the perfect aggregation switch for enterprise networks and high-throughput distribution cores. Highlights 16-port fully managed 10G switch: (12) SFP+ + (4) RJ45 10G ports 160 Gbps non-blocking throughput for high-performance aggregation 1U rackmount design with robust AC/DC dual power input Built-in ESD protection for enhanced hardware resilience Compatible with UniFi and EdgeMax environments Key Features Networking Interfaces 12 x 1/10 Gbps SFP+ ports 4 x 1/10 Gbps RJ45 copper Ethernet ports 1 x RJ45 serial console for in-band management Performance Switching Capacity: 320 Gbps Forwarding Rate: 238 Mpps (at 64-byte packets) Total Non-Blocking Throughput: 160 Gbps Power & Hardware Power Supply: 56W internal AC/DC PSU Power Input:  • AC: 100–240V AC, 50/60 Hz  • DC: 25–16V via 2.5 mm inline DC connector Max Power Consumption: 36W (Excludes module power draw) ESD/EMP Protection: ±24kV air/contact Physical & Environmental Dimensions: 443 x 221 x 43 mm (17.4 x 8.7 x 1.7 in) Weight:  • Without brackets: 2.6 kg (5.8 lb)  • With brackets: 2.7 kg (6 lb) Mounting: 1U rackmount (brackets included) LEDs: Speed/Link/Activity indicators on all ports Operating Temperature: -5 to 40°C (23 to 104°F) Humidity: 5 to 95% noncondensing Shock/Vibration Standard: ETSI300-019-1.4 Certifications & Compliance Certifications: CE, FCC, IC NDAA Compliant: Yes Summary The Ubiquiti ES-16-XG EdgeSwitch is a high-performance 10G aggregation switch built for demanding enterprise and datacenter environments. With a full set of SFP+ and RJ45 10G ports, robust power options, and non-blocking performance, it supports seamless high-throughput routing and switching at the network core. Magbasa pa
