D-Link DIS-100G-8SW 6-Port Gigabit Unmanaged Industrial Switch with SFP
Paglalarawan
Rugged 6-Port Gigabit Industrial Switch with SFP
Durable, Reliable, and Efficient Networking Solution for Industrial Applications
The D-Link DIS-100G-8SW is designed for the most demanding industrial environments. Featuring 6 x 10/100/1000BASE-T ports and 2 x SFP ports, this unmanaged switch provides high-performance networking. The switch is housed in an IP30-rated, fanless metal casing, offering durability and protection. With a wide operating temperature range of -40°C to +75°C, it ensures reliable performance in harsh conditions.
Highlights
- Wide Operating Temperature: Operates reliably between -40°C and +75°C
- Redundant Power Inputs: Dual power inputs for backup in case of primary power failure
- Rugged Design: IP30-rated metal housing, with DIN-rail and wall mounting options
- Electromagnetic Compatibility: High EMC endurance for environments with strong interference
- Certified for Industrial Standards: Compliant with EN-50121-4 wayside control and NEMA-TS2 traffic control standards
Key Features
- 6 x 10/100/1000BASE-T Ports: Provides fast and reliable gigabit data transfer
- 2 x SFP Ports: Supports additional fiber optic connections for extended range
- IP30-Rated Housing: Durable protection for tough industrial environments
- Wide Temperature Range: Operates in extreme environments (-40°C to +75°C)
- Dual Power Inputs: Ensures continuous operation with redundant power supplies
- Fanless Design: Silent, reliable operation with an extended lifespan
- High EMC Endurance: Designed to handle environments with high electromagnetic interference
- Industry Certifications: Fully compliant with EN-50121-4 and NEMA-TS2 for safe use in transportation and traffic systems
Summary
The D-Link DIS-100G-8SW is a robust and reliable industrial switch perfect for high-performance networking in harsh environments. With 6 gigabit ports, SFP support, and a rugged IP30-rated metal design, it ensures durability and efficiency. Its wide operating temperature range and dual power inputs guarantee continuous operation, making it ideal for transportation, surveillance, and other industrial applications.
Mga detalye
| Specification | Details |
|---|---|
| 10/100/1000 BASE-T ports | 6 |
| 1000Base-T Interface | 6 |
| SEP ports | 2 |
| 1000M SFP Interface | 2 |
| Auto MDI/MDIX | Yes |
| Alarm Port | Yes |
| Switching Capacity | 16Gbps |
| Max. Packet Forwarding Rate | 11.9Mpps |
| Dimensions | 117.8 x 39 x 96.9 mm |
| Weight | 0.448 kg |
| Operation Temperature | -40 to 75°C |
| Storage Temperature | -40 to 85°C |
| Operation Humidity | 5 to 95% RH |
| Storage Humidity | 5 to 95% RH |
| Maximum Heat Dissipation | 29 BTU/hr |
| Operating Altitude | 2000m |
| Maximum Power Consumption | 8.5W |
| MTBF | > 25 years |
| Power Input | 12-58Vdc |
| Fan | Fanless |
