High-Speed Cat6 Cabling for Safer Indoor Networks

Engineered for structured cabling in enterprise and commercial buildings, these UniFi Cat6 cables offer performance up to 10 Gbps and superior flame resistance — available in both CMR and CMP variants.

Highlights

  • 305 m (1,000 ft) reel of indoor Cat6 Ethernet cable

  • Solid bare copper, UTP 23 AWG with anti-crosstalk divider

  • Supports up to 10 Gbps (10GBase-T) over 55 m

  • CMR riser-rated or CMP plenum-rated flame-resistant options

  • Designed for UniFi access points, switches, and gateways

Key Features

Shared Specs

  • Cable Type: Category 6

  • Conductor: Solid bare copper, 23 AWG

  • Shielding Type: UTP

  • Ripcord: Yes

  • Anti-Crosstalk Divider: Yes

  • Reference Bandwidth: Up to 600 MHz

  • Supported Data Rate: Up to 10 Gbps (10GBase-T), max. 55 meters

  • Cable Length: 305 m (1,000 ft)

  • Color: White

  • Pulling Tension: Max. 110 N

  • Box Dimensions: 474 x 346 x 458 mm (18.7 x 13.6 x 18 inches)

  • Box Weight: 14.8 kg (32.7 lb for CMR, 32.5 lb for CMP)

CMR Variant (Riser-Rated)

  • Jacket Material: PVC

  • Jacket Diameter: 6.0 Âą 0.2 mm

  • Bend Radius: Min. 24 mm

  • Flame Rating: CMR (UL 1666)

CMP Variant (Plenum-Rated)

  • Jacket Material: Low smoke flame-retardant PVC

  • Jacket Diameter: 5.6 Âą 0.2 mm

  • Bend Radius: Min. 22.4 mm

  • Flame Rating: CMP (NFPA 262)

Summary

The Ubiquiti U-Cable-C6 series delivers enterprise-grade Category 6 Ethernet performance in indoor environments requiring strict fire-safety compliance. With robust build quality, anti-crosstalk shielding, and full 10 Gbps support, it’s the perfect match for modern UniFi infrastructure. Choose between CMR riser-rated or CMP plenum-rated options based on building code and installation zone.
Mga detalye

Ubiquiti U-Cable-C6 305M – UniFi Indoor Fire-Resistant Cat6 Ethernet Cable (CMR & CMP)

The Ubiquiti U-Cable-C6 is a high-performance Category 6 Ethernet cable engineered for indoor riser (CMR) and plenum (CMP) deployments. Designed for 10G data transmission with up to 600 MHz bandwidth, it features a solid copper core, anti-crosstalk divider, and fire-resistant jacket for enhanced safety in demanding environments.

Specifications

Specification CMR Version CMP Version
Type Category 6 UTP communications multipurpose cable Category 6 UTP communications multipurpose cable
Cable Length 305 m (1,000 ft) 305 m (1,000 ft)
Supported Data Rate Up to 10 Gbps (10GBase-T), Max 55 m Up to 10 Gbps (10GBase-T), Max 55 m
Reference Bandwidth Up to 600 MHz Up to 600 MHz
Flame Rating CMR (UL 1666) CMP (NFPA 262)
Shielding Type UTP (Unshielded Twisted Pair) UTP (Unshielded Twisted Pair)
Anti-Crosstalk Divider Yes Yes
Ripcord Yes Yes
Conductor Type Solid bare copper Solid bare copper
Conductor Wire Gauge 23 AWG 23 AWG
Jacket Diameter 6.0 Âą 0.2 mm 5.6 Âą 0.2 mm
Jacket Material PVC Low smoke flame retardant PVC
Bend Radius (Min.) 24 mm 22.4 mm
Pulling Tension (Max.) 110 N 110 N
Color White White
Box Dimensions (L × W × H) 474 × 346 × 458 mm (18.7 × 13.6 × 18") 474 × 346 × 458 mm (18.7 × 13.6 × 18")
Box Weight 14.8 kg (32.7 lb) 14.8 kg (32.5 lb)
Installation Temperature 0 to 60°C (32 to 140°F) 0 to 60°C (32 to 140°F)
Storage Temperature -20 to 75°C (-4 to 167°F) -20 to 75°C (-4 to 167°F)
Ambient Operating Temperature -20 to 60°C (-4 to 140°F) -20 to 60°C (-4 to 140°F)
Standards – Electrical ANSI/TIA-568-C.2 (2009), ISO/IEC 11801 (Ed. 2.2), IEC 61156-5 (Ed. 2.1) ANSI/TIA-568-C.2 (2009), ISO/IEC 11801 (Ed. 2.2), IEC 61156-5 (Ed. 2.1)
Standards – Flame Test UL 1666 (CMR) NFPA 262 (CMP)
Material & Safety UL 444, CSA 22.2 NO.214, RoHS2, LVD Directive UL 444, CSA 22.2 NO.214, RoHS2, LVD Directive
