TP-Link InSight S345ZI VIGI 4MP Outdoor IR Motorized Varifocal Bullet Network Camera
Paglalarawan
Precision Outdoor Surveillance with High Definition Clarity
The TP-Link InSight S345ZI VIGI 4MP Outdoor IR Motorized Varifocal Bullet Network Camera combines 4MP super-high definition, smart detection, and enhanced video technology to provide clear, reliable security monitoring in outdoor environments. With a robust design and advanced H.265+ compression, this camera offers effective, low-maintenance security for high-traffic areas.
Highlights
- 4MP Super-High Definition: Captures detailed images, with an IR range up to 60m (197ft)
- 5X Optical Zoom: Motorized varifocal lens allows precise focus on specific areas
- Human & Vehicle Classification: Reduces false alerts for accurate event notifications
- Smart Video Enhancement: Includes True WDR, Smart IR, 3D DNR, and White Balance for optimal image quality
- Weatherproof & Vandal-Proof: IP67 and IK10 ratings for rugged outdoor reliability
- H.265+ Compression: Reduces bandwidth and storage usage without compromising quality
Key Features
Motorized Varifocal Lens with 5X Optical Zoom
- Adjustable Field of View: Customize focus on key areas, reducing irrelevant zones.
- Enhanced Clarity: 5X zoom provides detailed views even at a distance, ideal for precise monitoring.
Intelligent Detection & Classification
- Human & Vehicle Identification: Differentiates between people, vehicles, and other objects for targeted alerts.
- Customizable Alerts: Filter notifications to detect specific activities, enhancing event accuracy.
Advanced Video Enhancement Technologies
- True WDR: Balances exposure in high-contrast lighting, delivering well-lit, clear images.
- Smart IR: Automatically adjusts IR intensity to avoid overexposure and improve night vision.
- 3D DNR: Reduces noise across frames, preserving image detail, especially in low-light.
- White Balance: Maintains color accuracy under varying lighting conditions.
Efficient Storage & Bandwidth Optimization
- H.265+ Compression: Significantly reduces storage needs by 57.5% over H.264, ideal for long-term recording.*
Summary
The TP-Link InSight S345ZI VIGI 4MP Outdoor IR Motorized Varifocal Bullet Network Camera provides reliable and precise outdoor surveillance. Its high-definition video, motorized zoom, smart detection, and rugged design make it a powerful solution for businesses and properties needing enhanced outdoor security, all while minimizing storage requirements with H.265+ compression.
Mga detalye
TP-Link InSight S345ZI VIGI 4MP Outdoor IR Motorized Varifocal Bullet Network Camera
| Specification | Details |
|---|---|
| Image Sensor | 1/2.9â Progressive Scan CMOS |
| Shutter Speed | 1/3 to 1/10000 s |
| Slow Shutter | Yes |
| Minimum Illumination | 0.005 Lux; 0 Lux with IR Light |
| Day/Night Mechanism | IR Cut Filter |
| Day/Night Switch | Unified/Scheduled/Auto |
| Lens Type | Motorized Varifocal Lens |
| Focal Length | 2.7-13.5 mm (5X Optical Zoom) |
| Aperture | F1.6 |
| Field of View (FOV) | âĸ Horizontal: 29.6°-102.0° âĸ Vertical: 16.8°-53.8° âĸ Diagonal: 34.1°-122.8° |
| DORI Distance | âĸ Detect: 66-207 m (217-579 ft) âĸ Observe: 28-86 m (92-282 ft) âĸ Recognize: 13-41 m (43-135 ft) âĸ Identify: 7-21 m (23-69 ft) |
| Angle Adjustment | âĸ Pan: 0° to 360° âĸ Tilt: 0° to 90° âĸ Rotation: 0° to 360° |
| IR LED | âĸ Quantity: 4 âĸ Range: 60 m (197 ft) âĸ Wavelength: 850 nm |
| Max. Resolution | 2688 x 1520 |
| Main Stream Frame Rate | âĸ 50Hz: 1fps, 5fps, 10fps, 15fps, 20fps, 25fps âĸ 60Hz: 1fps, 5fps, 10fps, 15fps, 20fps, 25fps, 30fps |
| Main Stream Resolution | 2688x1520, 2560x1440, 2304x1296, 2048x1280, 1920x1080 |
| Sub-Stream Frame Rate | âĸ 50Hz: 1fps, 5fps, 10fps, 15fps, 20fps, 25fps âĸ 60Hz: 1fps, 5fps, 10fps, 15fps, 20fps, 25fps, 30fps |
| Sub-Stream Resolution | 1280x720, 848x480, 704x576, 640x480, 640x360, 352x288, 320x240 |
| Bit Rate Control | CBR, VBR |
| Video Compression | âĸ Main Stream: H.265+/H.265/H.264+/H.264 âĸ Sub-Stream: H.265/H.264 |
| Audio Communication | Two-Way Audio |
| Audio Input/Output | Yes |
| Audio Bit Rate | 64 Kbps (G.711 alaw) |
| Protocol | TCP/IP, UDP, ICMP, HTTP, HTTPS, DHCP, DNS, RTSP, NTP, UPnP, SSL/TLS, FTP/SFTP, RTP, IPv4, IPv6, ARP |
| ONVIF | Yes |
| Simultaneous Live View | 3 Main Streams & 3 Sub-Streams |
| Client | VIGI App, VIGI Security Manager, Web UI, VIGI VMS, VIGI Cloud VMS |
| Smart Events | Intrusion, Line-Crossing, Region Entering/Exiting Detection, Object Abandoned, Loitering, People & Vehicle Detection |
| Basic Events | Motion Detection (with Human & Vehicle Classification), Video Tampering, Illegal Login Exception |
| Network Interface | 1 RJ45 10/100M Self-Adaptive Ethernet Port, PoE |
| Alarm Interface | 1 Alarm In, 1 Alarm Out |
| Reset Button | Yes |
| On-board Storage | Supports MicroSD Card, up to 512 GB |
| Built-in Microphone | Yes, records within 15-ft radius |
| Operating Temperature | -30â60 °C |
| Storage Temperature | -40â60 °C |
| Operating Humidity | 95% or Less (Non-Condensing) |
| Package Contents | âĸ VIGI Network Camera âĸ Quick Start Guide âĸ Waterproof Cable Attachments âĸ Mounting Accessories |
| Material | Metal |
| Net Weight | 1.04 Kg |
| Power Supply | âĸ 12V DC Âą 5%, Max. 10.8 W âĸ PoE: 802.3af/at, class 0, Max. 12 W |
| Protection | IP67 Weatherproof, IK10 Vandal Proof |
| Product Dimensions | 10.1 Ã 3.9 Ã 4 in (256 Ã 100 Ã 101 mm) |
| Certifications | CE, NTRA, VCCI, KC, BSMI, FCC, IP67, IK10, ONVIF |
